ELV
We have a highly qualified Team of ELV system designers and BIM Modelers to provide added value to the Clients through specialized ELV System services. Our knowledge and experience of ELV Design coupled with our extensively skilled Team ensure deliverables are of highest possible accuracy and are competitively priced. We provide ELV design services throughout all phases of the Projects in compliance with Project’s BIM Execution plan and LOD requirements.
| Design Stages | Concept Design Stage | Schematic Design Stage | Detail Design Stage | Tender Stage | IFC Stage |
|---|---|---|---|---|---|
| LOD Level | LOD 100 | LOD 200 | LOD 300 | LOD 300 | LOD 300/400 |
| Services | ICT-Telecom-Structured Cabling | Security Systems | Fire Alarm Systems | Audio Visual Systems | Acoustics |
|---|
- AutoCAD 2D design
- BIM 3D design
- Coordination with various disciplines
- Navisworks Clash Detection
- System Layouts
- Elevations and sections
- Enlarged Layouts
- Rack Elevations
- BOQ
- Schematics and Riser Diagrams
- Model exchange in various formats as required- RVT/NWC/NWD/IFC/DWFx/PDF
ELV Services include the following, but not limited to the below:-
